The Biological Carbon Pump
The biological carbon pump (BCP): the ocean’s role in the global carbon cycle and climate regulation
The ocean is a central cog in the global carbon cycle and one of the largest active carbon reservoirs; storing ~50 times the amount of carbon held in the atmosphere and driving 30% of the annual net removal of anthropogenic carbon dioxide (CO₂) (Sarmiento and Gruber, 2006; DeVries, 2022; Iversen, 2023). This net uptake of atmospheric CO₂ by the global ocean actively lowers atmospheric CO₂ concentrations and plays a major role in regulating the Earth’s climate, the extent to which has been hypothesized to be associated with glacial and interglacial climate variability (Broecker, 1982; Sigman and Boyle, 2000). The magnitude of this inorganic carbon storage gradient from the atmosphere to the deep ocean is governed by two mechanisms; the solubility and the biological carbon pumps (BCP) (Volk and Hoffert, 1985; McKinley et al., 2016). The former, driven by temperature, underpins the bulk of oceanic CO₂ uptake at the atmosphere-ocean surface interface while the latter, the BCP, accounts for ~90% of the contemporary storage gradient observed today (Sarmiento and Gruber, 2006). Believed to be the dominant component of the BCP, the gravitational sinking of newly formed particulate organic matter (POM) by phytoplankton photosynthesis (the fixing of inorganic CO₂ into organic carbon by ubiquitous single-celled marine algae) connects surface and deep ocean processes on shorter time scales (days to weeks) than physical advection (decades to centuries) (Boyd and Trull, 2007; Buesseler et al., 2007) and drives long-term storage in the deep ocean on centennial timescales (Volk and Hoffert, 1985; Sigman and Boyle, 2000; Ducklow, Steinberg and Buesseler, 2001). This sinking POM is largely composed of detrital material (i.e., dead phytoplankton cells and fecal pellets produced from zooplankton – heterotrophic consumers), aggregates and living microbial cells (Turner, 2015; Boyd et al., 2019). While the vast majority of flux attenuation (70 – 85%) occurs within the mesopelagic (~200 – 1000 m) primarily due to microbe-mediated diagenetic transformations (Martin et al., 1987; Karl et al., 1988; Buesseler and Boyd, 2009; Guidi et al., 2015), the strength (i.e., the rate of organic carbon export) and efficiency (i.e., the extent to which newly supplied nutrients are consumed and thus support export production) of the BCP is largely governed by euphotic zone (sunlit upper layer of the ocean) food-web structures and system productivity, and thus is not uniform across the global ocean (Boyd et al., 2024; Stukel et al., 2024).
70 - 85% particle organic matter flux attenuation
Zooplankton consumption/ ‘sloppy feeding’
Microbial diagenesis
Particle fragmentation
Drivers of the BCP: nutrient availability and food-web structure
Marine macro- and micronutrient landscapes govern productivity regimes, shaping subsequent plankton community dynamics and export fluxes (Dugdale and Goering, 1967; Moore et al., 2013; Stukel and Barbeau, 2020). Essential macronutrients including nitrate, ammonium, phosphate and at times silicic acid, as well as micronutrients including iron are required by and often (co-)limiting for all phytoplankton taxa (Dugdale and Goering, 1967; de Baar et al., 1995; Browning and Moore, 2023). The availability (or limitation) of these nutrients broadly defines important marine biogeochemical regions and exerts a strong control on phytoplankton community composition (Deutsch and Weber, 2012; Moore et al., 2013). Productive upwelling and mixing regions are generally observed to have cooler, more active (with regards to surface water mass overturning) euphotic zones that are nutrient replete, supporting rapid growth of large phytoplankton taxa (e.g., diatoms) and successive mesozooplankton communities (Stukel et al., 2011, 2013, 2023; Valencia et al., 2022; Browning and Moore, 2023). Conversely, oligotrophic regions are largely defined by warmer, stratified euphotic zones that are nitrate (and/or phosphate and iron) (co-)limited, supporting small phytoplankton taxa (e.g., cyanobacteria and picoplankton) and microzooplankton communities (Stukel et al., 2011; Selph et al., 2022; Valencia et al., 2022; Browning and Moore, 2023). Although biogeochemical regions supporting food-webs of larger phytoplankton and mesozooplankton are generally observed to drive higher export fluxes (Krause et al., 2015; Stukel et al., 2017; Buesseler et al., 2008b), an increasing body of literature describes elevated export efficiencies in more oligotrophic regions (Puigcorbé et al., 2015; Mouw et al., 2016; Stukel and Barbeau, 2020) .
Nitrogen (N) is arguably the most influential growth-limiting element across the global ocean (Moore et al., 2013; Browning and Moore, 2023). While bioavailable in numerous forms including nitrate, nitrite and ammonium, with the former constituting the largest marine N pool, the marine N inventory is unique to other elemental cycles (e.g., carbon and phosphorus) since the sources/losses are largely controlled by biological processes. The biological fixation of dinitrogen (N₂) gas, mediated primarily by marine prokaryotes (“diazotrophs”), is the largest source of newly fixed N to the global ocean, while denitrification and anammox control the loss terms of the marine N budget (Gruber, 2004; Zehr and Kudela, 2011; Casciotti, 2016; Landolfi et al., 2018). Although the global rate and distribution of marine N₂ fixation remains uncertain and is co-limited by diazotrophic iron and phosphorus requirements (Moore et al., 2009; Monteiro et al., 2011; Dutkiewicz et al., 2012; Weber and Deutsch, 2014), this process is observed to predominantly occur in oligotrophic surface waters and has large ecological impacts on marine food-web structures and subsequent biogeochemical impacts on carbon export potential (Dugdale and Goering, 1967; Karl et al., 1997; Capone, 2001; Capone et al., 2005). Although export in oligotrophic regions is observed to be very low, areas of high euphotic zone N₂ fixation in the western tropical South Pacific (WTSP) have recently been associated with elevated export fluxes (Bonnet et al., 2023b, 2023a), suggesting a uniquely amplified BCP in an otherwise oligotrophic region. Conversely, regions with nitrate-replete euphotic zones including upwelling regions and the high-nutrient, low-chlorophyll Southern Ocean are observed to promote stronger BCPs with variable efficiencies due to micronutrient (largely iron) availability (Stukel and Ducklow, 2017; Stukel et al., 2017, 2023; Décima et al., 2023).
Current approaches constraining BCP variability
Considering the vast implications the BCP has for climate regulation and potential mitigative impacts on anthropogenic-driven climate change, the spatial and temporal patterns of the strength and efficiency of the BCP have been a key research focus for close to three decades. As a result, a variety of approaches have been developed to investigate and constrain the observed variability and magnitude of the BCP. Direct in situ field observations and sample collection often include the deployment of sediment traps to capture sinking POM throughout the mesopelagic and deep ocean, followed up with an array of chemical analyses of the particulate material (Volk and Hoffert, 1985; Martin et al., 1987; Buesseler et al., 2008b). Export estimates can be measured using radionuclide disequilibrium approaches (between 238U and 234Th, the latter adhering to POM; Henson et al., 2011; Owens et al., 2011; Stukel et al., 2019), and nutrient mass balance proxies and budgets, particularly relating to N, and largely focusing on productivity metrics within the euphotic zone (Fawcett et al., 2011; Yingling et al., 2022; Stirnimann et al., 2024). Recent research has focused on different pathways driving this export such as phytoplankton size and system productivity (Stukel et al., 2024), phytoplankton community contributions (e.g., diatoms; Krause et al., 2015), and zooplankton community contributions (e.g., salps; Décima et al., 2023). Additional advancements in genetic sequencing through metabarcoding, has aimed to constrain the microbial communities that drive remineralization processes, while further enumerating phytoplankton taxa contribution to sinking fluxes (Amacher et al., 2013; Guidi et al., 2016; Valencia et al., 2021, 2021). Together, the methods above describe various frameworks to assess the strength, efficiency and variability of the BCP.
These approaches along with satellite data often form the foundation for data-assimilative modeling approaches used to quantify the BCP on a global scale, including food-web models and biogeochemical inverse models (Siegel et al., 2014; DeVries and Weber, 2017; Nowicki et al., 2022). Despite extensive work, large discrepancies remain across measurements and models, describing poorly constrained BCP estimates with large uncertainties (varying from ~5 – 12 Pg carbon per year; Laws et al., 2000, 2011; Henson et al., 2011; Siegel et al., 2014; DeVries and Weber, 2017; Nowicki et al., 2022). This indicates continued critical knowledge gaps in BCP variability that are manifested in the general spatial and temporal inconsistency of in situ measurements as well as our insufficient understanding of the various BCP mechanisms, specifically 1) drivers of export flux in N-limited regions, accounting for much of the global ocean, and 2) the molecular-level composition (presence of individual molecules) of sinking POM and how this changes over trophic gradients with varying food-web structures. Greater insights into these mechanisms, such as the molecular-level composition of sinking POM (largely reflecting the major organic compounds of life such as carbohydrates, proteins, lipids, and amino acids), will allow for a greater understanding of BCP variability while having large implications for nutrient cycling and ecosystem functioning today and in a warming world.
Examples of in situ observations of the BCP magnitude
Niskin rosette collects water column samples
Sediment trap deployment
Satellite/remote observations
Global BCP estimates
References:
Amacher, J., Neuer, S. and Lomas, M. (2013) ‘DNA-based molecular fingerprinting of eukaryotic protists and cyanobacteria contributing to sinking particle flux at the Bermuda Atlantic time-series study’, Deep Sea Research Part II: Topical Studies in Oceanography, 93, pp. 71–83. Available at: https://doi.org/10.1016/j.dsr2.2013.01.001.
de Baar, H.J.W. et al. (1995) ‘Importance of iron for plankton blooms and carbon dioxide drawdown in the Southern Ocean’, Nature, 373(6513), pp. 412–415. Available at: https://doi.org/10.1038/373412a0.
Bonnet, S. et al. (2023a) ‘Diazotrophs are overlooked contributors to carbon and nitrogen export to the deep ocean’, The ISME Journal, 17(1), pp. 47–58. Available at: https://doi.org/10.1038/s41396-022-01319-3.
Bonnet, S. et al. (2023b) ‘Natural iron fertilization by shallow hydrothermal sources fuels diazotroph blooms in the ocean’, Science, 380(6647), pp. 812–817. Available at: https://doi.org/10.1126/science.abq4654.
Boyd, P.W. et al. (2019) ‘Multi-faceted particle pumps drive carbon sequestration in the ocean’, Nature, 568(7752), pp. 327–335. Available at: https://doi.org/10.1038/s41586-019-1098-2.
Boyd, P.W. et al. (2024) ‘The role of biota in the Southern Ocean carbon cycle’, Nature Reviews Earth & Environment, pp. 1–19.
Boyd, P.W. and Trull, T.W. (2007) ‘Understanding the export of biogenic particles in oceanic waters: Is there consensus?’, Progress in Oceanography, 72(4), pp. 276–312. Available at: https://doi.org/10.1016/j.pocean.2006.10.007.
Broecker, W.S. (1982) ‘Glacial to interglacial changes in ocean chemistry’, Progress in Oceanography, 11(2), pp. 151–197. Available at: https://doi.org/10.1016/0079-6611(82)90007-6.
Browning, T.J. and Moore, C.M. (2023) ‘Global analysis of ocean phytoplankton nutrient limitation reveals high prevalence of co-limitation’, Nature Communications, 14(1), p. 5014. Available at: https://doi.org/10.1038/s41467-023-40774-0.
Buesseler, K.O. et al. (2007) ‘An assessment of the use of sediment traps for estimating upper ocean particle fluxes’, Journal of Marine Research, 65(3), pp. 345–416. Available at: https://doi.org/10.1357/002224007781567621.
Buesseler, K.O. et al. (2008b) ‘VERTIGO (VERtical Transport In the Global Ocean): A study of particle sources and flux attenuation in the North Pacific’, Deep Sea Research Part II: Topical Studies in Oceanography, 55(14–15), pp. 1522–1539. Available at: https://doi.org/10.1016/j.dsr2.2008.04.024.
Buesseler, K.O. and Boyd, P.W. (2009) ‘Shedding light on processes that control particle export and flux attenuation in the twilight zone of the open ocean’, Limnology and Oceanography, 54(4), pp. 1210–1232. Available at: https://doi.org/10.4319/lo.2009.54.4.1210.
Capone, D.G. (2001) ‘Marine nitrogen fixation: what’s the fuss?’, Current Opinion in Microbiology, 4(3), pp. 341–348. Available at: https://doi.org/10.1016/S1369-5274(00)00215-0.
Capone, D.G. et al. (2005) ‘Nitrogen fixation by Trichodesmium spp.: An important source of new nitrogen to the tropical and subtropical North Atlantic Ocean’, Global Biogeochemical Cycles, 19(2), p. n/a-n/a. Available at: https://doi.org/10.1029/2004GB002331.
Casciotti, K.L. (2016) ‘Nitrogen and oxygen isotopic studies of the marine nitrogen cycle’, Annual review of marine science, 8, pp. 379–407.
Décima, M. et al. (2023) ‘Salp blooms drive strong increases in passive carbon export in the Southern Ocean’, Nature Communications, 14(1), p. 425. Available at: https://doi.org/10.1038/s41467-022-35204-6.
Deutsch, C. and Weber, T. (2012) ‘Nutrient ratios as a tracer and driver of ocean biogeochemistry’, Annual review of marine science, 4, pp. 113–141.
DeVries, T. (2022) ‘The Ocean Carbon Cycle’, Annual Review of Environment and Resources, 47(1), pp. 317–341. Available at: https://doi.org/10.1146/annurev-environ-120920-111307.
DeVries, T. and Weber, T. (2017) ‘The export and fate of organic matter in the ocean: New constraints from combining satellite and oceanographic tracer observations’, Global Biogeochemical Cycles, 31(3), pp. 535–555. Available at: https://doi.org/10.1002/2016GB005551.
Ducklow, H., Steinberg, D. and Buesseler, K. (2001) ‘Upper Ocean Carbon Export and the Biological Pump’, Oceanography, 14(4), pp. 50–58. Available at: https://doi.org/10.5670/oceanog.2001.06.
Dugdale, R.C. and Goering, J.J. (1967) ‘Uptake of new and regenerated forms of nitrogen in primary productivity: uptake of nitrogen in primary productivity’, Limnology and Oceanography, 12(2), pp. 196–206. Available at: https://doi.org/10.4319/lo.1967.12.2.0196.
Dutkiewicz, S. et al. (2012) ‘Interconnection of nitrogen fixers and iron in the Pacific Ocean: Theory and numerical simulations’, Global Biogeochemical Cycles, 26(1), p. n/a-n/a. Available at: https://doi.org/10.1029/2011GB004039.
Fawcett, S.E. et al. (2011) ‘Assimilation of upwelled nitrate by small eukaryotes in the Sargasso Sea’, Nature Geoscience, 4(10), pp. 717–722. Available at: https://doi.org/10.1038/ngeo1265.
Gruber, N. (2004) ‘The Dynamics of the Marine Nitrogen Cycle and its Influence on Atmospheric CO2 Variations’, in M. Follows and T. Oguz (eds) The Ocean Carbon Cycle and Climate. Dordrecht: Springer Netherlands, pp. 97–148. Available at: https://doi.org/10.1007/978-1-4020-2087-2_4.
Guidi, L. et al. (2015) ‘A new look at ocean carbon remineralization for estimating deepwater sequestration: ocean remineralization and sequestration’, Global Biogeochemical Cycles, 29(7), pp. 1044–1059. Available at: https://doi.org/10.1002/2014GB005063.
Guidi, L. et al. (2016) ‘Plankton networks driving carbon export in the oligotrophic ocean’, Nature, 532(7600), pp. 465–470. Available at: https://doi.org/10.1038/nature16942.
Henson, S.A. et al. (2011) ‘A reduced estimate of the strength of the ocean’s biological carbon pump’, Geophysical Research Letters, 38(4). Available at: https://doi.org/10.1029/2011GL046735.
Iversen, M.H. (2023) ‘Carbon Export in the Ocean: A Biologist’s Perspective’, Annual Review of Marine Science, 15(1), pp. 357–381. Available at: https://doi.org/10.1146/annurev-marine-032122-035153.
Karl, D. et al. (1997) ‘The role of nitrogen fixation in biogeochemical cycling in the subtropical North Pacific Ocean’, Nature, 388(6642), pp. 533–538. Available at: https://doi.org/10.1038/41474.
Karl, D.M., Knauer, G.A. and Martin, J.H. (1988) ‘Downward flux of particulate organic matter in the ocean: a particle decomposition paradox’, Nature, 332(6163), pp. 438–441. Available at: https://doi.org/10.1038/332438a0.
Krause, J.W. et al. (2015) ‘Variability in diatom contributions to biomass, organic matter production and export across a frontal gradient in the California Current Ecosystem’, Journal of Geophysical Research: Oceans, 120(2), pp. 1032–1047. Available at: https://doi.org/10.1002/2014JC010472.
Landolfi, A. et al. (2018) ‘Global Marine N2 Fixation Estimates: From Observations to Models’, Frontiers in Microbiology, 9, p. 2112. Available at: https://doi.org/10.3389/fmicb.2018.02112.
Laws, E.A. et al. (2000) ‘Temperature effects on export production in the open ocean’, Global Biogeochemical Cycles, 14(4), pp. 1231–1246. Available at: https://doi.org/10.1029/1999GB001229.
Laws, E.A., D’Sa, E. and Naik, P. (2011) ‘Simple equations to estimate ratios of new or export production to total production from satellite-derived estimates of sea surface temperature and primary production’, Limnology and Oceanography: Methods, 9(12), pp. 593–601. Available at: https://doi.org/10.4319/lom.2011.9.593.
Martin, J.H. et al. (1987) ‘VERTEX: carbon cycling in the northeast Pacific’, Deep Sea Research Part A. Oceanographic Research Papers, 34(2), pp. 267–285. Available at: https://doi.org/10.1016/0198-0149(87)90086-0.
McKinley, G.A. et al. (2016) ‘Timescales for detection of trends in the ocean carbon sink’, Nature, 530(7591), pp. 469–472.
Monteiro, F.M., Dutkiewicz, S. and Follows, M.J. (2011) ‘Biogeographical controls on the marine nitrogen fixers’, Global Biogeochemical Cycles, 25(2), p. n/a-n/a. Available at: https://doi.org/10.1029/2010GB003902.
Moore et al. (2009) ‘Large-scale distribution of Atlantic nitrogen fixation controlled by iron availability’, Nature Geoscience, 2(12), pp. 867–871. Available at: https://doi.org/10.1038/ngeo667.
Moore, C.M. et al. (2013) ‘Processes and patterns of oceanic nutrient limitation’, Nature Geoscience, 6(9), pp. 701–710. Available at: https://doi.org/10.1038/ngeo1765.
Mouw, C.B. et al. (2016) ‘Phytoplankton size impact on export flux in the global ocean’, Global Biogeochemical Cycles, 30(10), pp. 1542–1562. Available at: https://doi.org/10.1002/2015GB005355.
Nowicki, M., DeVries, T. and Siegel, D.A. (2022) ‘Quantifying the Carbon Export and Sequestration Pathways of the Ocean’s Biological Carbon Pump’, Global Biogeochemical Cycles, 36(3), p. e2021GB007083. Available at: https://doi.org/10.1029/2021GB007083.
Owens, S.A., Buesseler, K.O. and Sims, K.W.W. (2011) ‘Re-evaluating the 238U-salinity relationship in seawater: Implications for the 238U–234Th disequilibrium method’, Marine Chemistry, 127(1), pp. 31–39. Available at: https://doi.org/10.1016/j.marchem.2011.07.005.
Puigcorbé, V. et al. (2015) ‘Small phytoplankton drive high summertime carbon and nutrient export in the Gulf of California and Eastern Tropical North Pacific’, Global Biogeochemical Cycles, 29(8), pp. 1309–1332. Available at: https://doi.org/10.1002/2015GB005134.
Sarmiento, J.L. and Gruber, N. (2006) Ocean Biogeochemical Dynamics. Princeton, NJ: Princeton Univ. Press.
Selph, K.E. et al. (2022) ‘Phytoplankton community composition and biomass in the oligotrophic Gulf of Mexico’, Journal of Plankton Research, 44(5), pp. 618–637.
Siegel, D.A. et al. (2014) ‘Global assessment of ocean carbon export by combining satellite observations and food-web models’, Global Biogeochemical Cycles, 28(3), pp. 181–196. Available at: https://doi.org/10.1002/2013GB004743.
Sigman, D.M. and Boyle, E.A. (2000) ‘Glacial/interglacial variations in atmospheric carbon dioxide’, Nature, 407(6806), pp. 859–869. Available at: https://doi.org/10.1038/35038000.
Stirnimann, L. et al. (2024) ‘A Circum‐Antarctic Plankton Isoscape: Carbon Export Potential Across the Summertime Southern Ocean’, Global Biogeochemical Cycles, 38(1), p. e2023GB007808. Available at: https://doi.org/10.1029/2023GB007808.
Stukel, M.R. et al. (2011) ‘Trophic cycling and carbon export relationships in the California Current Ecosystem’, Limnology and Oceanography, 56(5), pp. 1866–1878. Available at: https://doi.org/10.4319/lo.2011.56.5.1866.
Stukel, M.R. et al. (2013) ‘Contributions of mesozooplankton to vertical carbon export in a coastal upwelling system’, Marine Ecology Progress Series, 491, pp. 47–65.
Stukel, M.R. et al. (2017) ‘Mesoscale ocean fronts enhance carbon export due to gravitational sinking and subduction’, Proceedings of the National Academy of Sciences, 114(6), pp. 1252–1257. Available at: https://doi.org/10.1073/pnas.1609435114.
Stukel, M.R. et al. (2019) ‘The Carbon:234Thorium ratios of sinking particles in the California current ecosystem 1: relationships with plankton ecosystem dynamics’, Marine Chemistry, 212, pp. 1–15. Available at: https://doi.org/10.1016/j.marchem.2019.01.003.
Stukel, M.R. et al. (2023) ‘Carbon sequestration by multiple biological pump pathways in a coastal upwelling biome’, Nature Communications, 14(1), p. 2024. Available at: https://doi.org/10.1038/s41467-023-37771-8.
Stukel, M.R. et al. (2024) ‘Relationships Between Plankton Size Spectra, Net Primary Production, and the Biological Carbon Pump’, Global Biogeochemical Cycles, 38(4), p. e2023GB007994. Available at: https://doi.org/10.1029/2023GB007994.
Stukel, M.R. and Barbeau, K.A. (2020) ‘Investigating the Nutrient Landscape in a Coastal Upwelling Region and Its Relationship to the Biological Carbon Pump’, Geophysical Research Letters, 47(6). Available at: https://doi.org/10.1029/2020GL087351.
Stukel, M.R. and Ducklow, H.W. (2017) ‘Stirring Up the Biological Pump: Vertical Mixing and Carbon Export in the Southern Ocean’, Global Biogeochemical Cycles, 31(9), pp. 1420–1434. Available at: https://doi.org/10.1002/2017GB005652.
Turner, J.T. (2015) ‘Zooplankton fecal pellets, marine snow, phytodetritus and the ocean’s biological pump’, Progress in Oceanography, 130, pp. 205–248.
Valencia, B. et al. (2021) ‘Relating sinking and suspended microbial communities in the California Current Ecosystem: digestion resistance and the contributions of phytoplankton taxa to export’, Environmental Microbiology, 23(11), pp. 6734–6748. Available at: https://doi.org/10.1111/1462-2920.15736.
Valencia, B. et al. (2022) ‘Microbial communities associated with sinking particles across an environmental gradient from coastal upwelling to the oligotrophic ocean’, Deep Sea Research Part I: Oceanographic Research Papers, 179, p. 103668.
Volk, T. and Hoffert, M.I. (1985) ‘Ocean carbon pumps: Analysis of relative strengths and efficiencies in ocean‐driven atmospheric CO2 changes’, in E.T. Sundquist and W.S. Broecker (eds) The carbon cycle and atmospheric CO2: natural variations Archean to present. Washington, D. C.: American Geophysical Union, pp. 99–110. Available at: https://doi.org/10.1029/GM032p0099.
Weber, T. and Deutsch, C. (2014) ‘Local versus basin-scale limitation of marine nitrogen fixation’, Proceedings of the National Academy of Sciences, 111(24), pp. 8741–8746. Available at: https://doi.org/10.1073/pnas.1317193111.
Yingling, N. et al. (2022) ‘Taxon-specific phytoplankton growth, nutrient utilization and light limitation in the oligotrophic Gulf of Mexico’, Journal of Plankton Research, 44(5).
Zehr, J.P. and Kudela, R.M. (2011) ‘Nitrogen cycle of the open ocean: from genes to ecosystems’, Annual review of marine science, 3, pp. 197–225.
All information above taken from:
Forrer, H. J. (2024). Investigating Biological Carbon Pump Variability and Functionality: The Application of Old and New Conceptual Frameworks across Spatial and Temporal Scales. Doctoral dissertation, Florida State University, USA.
All graphics, unless credited, were created by Heather Forrer and use is encouraged. If you choose to, you can credit them as Heather Forrer.
